产品描述
BIDI SFP optical module contains 155Mb series , 1.25G, 2.5G. The product supports a variety of transmission distance from 500M to 120KM.It is characterized by low power consumption, small volume and wide temperature range.It is mainly used in SDH/SONET transmission and other environments.
特征
* Single Fiber Bi-directional Transmission
* Hot-pluggable SFP Footprint
* Single LC or SC Connector optional
* Wide Distance Supported from 500m to 120km
* Built-in Digital Diagnostic Monitor function
* Metal Enclosure for Lower EMI
* Comply with SFP MSA
* Comply with SDH/SONET
* Comply with IEEE Std 802.3
* Operation Temperature Range 0~70°C or -40~85°C optional
* Single +3.3V Power Supply
* RoHS-6 Compliant
应用
承诺
一年内提供免费维修或更换服务；
一年以上三年以内提供收材料成本费，免维修费的保修服务
规格
订货信息：
SFP-BX-D120-XW
|
TX1550nm/RX1490nm, 1.25Gbps, 120km,Standard 0 to +70°C/Industrial -40 to +85°C,SC/LC,DDM/NO DDM
|
|
SFP-BX-U120-XW
|
TX1490nm/TX1550nm, 1.25Gbps, 120km,Standard 0 to +70°C/Industrial -40 to +85°C,SC/LC,DDM/NO DDM
|
